This card can be easily connected to a low resolution CRT display.
Specifications:
1: Input power: DC 5V / 1A.
2: Input signal formats supported: 640×480 @ 60/72/75 / 85Hz, 800×600 @ 60 / 75Hz, 1024×768 @ 60 / 75Hz, 1280×1024 @ 60Hz.
3: Output RGBS formats supported: 15KHz horizontal frequency signal.
4: standard video output: CVBS, S terminals.
5, the technical characteristics:
6:24 bit professional video processing chip, a variety of video output signal.
7: good color reproduction, image no dry spots, no teeth.
8: plug and play, easy to operate.
9: multi-standard switch to adapt to various display tubes with national television.
GBS-8100 video converter board
DC line
2pin line
